JANOME Desktop Robot i22X Series Multifunctional Inspection Device
The Desktop Robot i22X Series, part of the JR3000 Series, is a multifunctional inspection device equipped with a powerful visual inspection system. It supports dip soldering, color difference, and optional OCR inspections. It efficiently checks missing screws and reads barcodes, saving results automatically. With features like RGB lighting and monthly productivity graphs, it is customizable to fit specific needs and enhances operational efficiency. ・Dip Soldering Inspection ・Part・Color Difference ・Scratch Inspection ・Text Inspection(Optical Character Recognition-optional add-on) ・Missing Screw Check ・Reads Various Barcodes
Traceability
Automatically saves inspection results & barcode information -Production Management Software "Catch System"*Optional (sold separately)
Inspection Range Up to 500mm
-“Free Space” Design Inspection StageChoose Lighting to Fit Your Application
-White Lighting・DOAL・RGB Lighting ・Red Side Lighting・MoreSystem Configuration
Inspection Unit・PC・Display・Controller・Switchbox
| Item | i22X-200 | i22X-300 | i22X-500 | i22XDA-300＊1 |
| External Dimensions | W420 D434 H696mm | W560 D587 H722mm/td> | W678 D731 H822mm | W560 D587 H722mm |
| Device Weight | 26kg | 43kg | 53kg | 53kg |
| Applicable Workpiece Size | W200 D200 H80mm | W320 D300 H100mm | W510 D510 H150mm | W280 D250 H40mm |
| Maximum Portable Load | 5kg | |||
