JANOME i22X-500 Multifunctional Inspection Device Demo Unit

JANOME i22X-500 Multifunctional Inspection Device Demo Unit

A dedicated inquiry page for a JANOME i22X-500 demo system—subject to current stock, condition and quotation.

The JANOME i22X-500 Multifunctional Inspection Device Demo Unit listing concerns a specific previously offered demonstration system, not an automatic guarantee of new-equipment stock. The historical listing refers to a unit carried over from a canceled project and mentions special pricing; current availability and commercial terms have not been verified.

Based on JANOME’s published i22X-500 model specification, the inspection stage accommodates workpieces up to 510 × 510 × 150 mm and a maximum portable load of 5 kg. The standard model has external dimensions of 678 × 731 × 822 mm and an equipment weight of 53 kg.

The i22X family supports image-based inspection of dip soldering, components, scratches, color differences, missing screws and barcodes. OCR and production traceability enhancements such as Catch System may require separately ordered options; the actual demo-unit hardware and license inventory must be checked.

Before quoting, confirm location, operational condition, camera and lighting configuration, software license transferability, calibration or inspection history, accessories, warranty/return terms, delivery charges and installation requirements. Customers seeking a configurable new unit should consult the standard i22X Series page.

i22X-500Large-format model
510 × 510 mmApplicable workpiece footprint
150 mmMaximum workpiece height
Inquiry firstCondition, price and stock to verify

Demo-Unit Inquiry

Ask about the exact unit and its current condition before treating the listing as an available offer.

Large Inspection Area

JANOME lists an applicable 510 × 510 × 150 mm workpiece envelope for the i22X-500 model.

Flexible Vision Inspection

Potential inspection tasks include solder, scratches, color variation, missing parts and barcodes.

Configurable Illumination

The i22X family offers white, DOAL, RGB and side lighting; confirm which are installed on this unit.

Optional Software Functions

OCR and Catch System are optional and may not be part of the demonstration-unit package.

Quote-Based Delivery Terms

Verify included components, packing, freight, any on-site setup and warranty before purchase.

PCB Visual Inspection Trial

Evaluate whether the existing vision and lighting setup fits inspection criteria for electronic assemblies.

Automated Component Check

Pilot missing-part or missing-screw checks at a desktop inspection station.

Product Traceability Pilot

Assess barcode capture and available software integration for factory inspection records.

Solder and Surface Comparison

Trial defect visibility and pass/fail criteria using actual customer samples.

Quality-Control Proof of Concept

Determine process feasibility ahead of any scale-up or new-system order.

Inspection Line Upgrade Evaluation

Compare a demonstration unit with requirements for a new i22X-500 configuration.

JANOME i22X-500 Multifunctional Inspection Device Demo Unit Specifications

The table reflects manufacturer i22X-500 platform specifications. The specific demo unit’s installed features, package contents, stock status, sale price and warranty have not been independently verified.

Published i22X-500 Model Specifications

SpecificationDetails
ModelJANOME i22X-500
Product roleCamera-based multifunctional visual inspection device
Applicable workpiece size (W × D × H)510 × 510 × 150 mm
Maximum portable load5 kg
External dimensions (W × D × H)678 × 731 × 822 mm
Published equipment weight53 kg
Family inspection functionsSolder, part/color difference, scratch, missing screw, barcode
Text OCROptional add-on; verify whether present on the demo unit
Catch System production softwareOptional and sold separately; verify license/package
LightingConfigurable family options include white, DOAL, RGB and red side; actual installed set TBD
System componentsInspection unit, PC, display, controller, switchbox; actual package TBD
Device manufacturerMarantz Electronics, Ltd. (JANOME-listed system)
Commercial statusAvailability and sale terms must be confirmed with Denkei Americas
