TESTS MUST BE FAST!
The brand new GSP-9330, a high test speed spectrum analyzer with 3.25 GHz, provides the fastest 204 μs sweep speed. Users, via high-speed sweep time, can easily handle and analyze modulation signals. The keys to handling modulated signals are fast sweep time and signal demodulation functions. In addition to the analog AM/FM demodulation and analysis function, GSP-9330 also provides digital signal ASK/FSK, and 2FSK demodulation and analysis capabilities. Nowadays, EMC issues are very crucial to product design processes. Therefore, GSP-9330 has incorporated the EMC pretest solution to facilitate EMC tests. The simple and easy EMC pretest procedures from GSP-9330 can tremendously shorten users' product launch timeline.• Frequency Range: 9kHz ~ 3.25GHz • 0.025ppm Frequency Stability and 1ppm aging Rate • RBW: 1Hz ~ 1MHz (3dB), 6dB EMI Filter: 200Hz, 9kHz, 120kHz, 1MHz • Fastest sweep time: 204us • Sensitivity: -149 dBm/Hz (@PreAmp on) • Built-in Preamplifier, 50dB Attenuator, and Sequence Function • Built-in EMC pretest function, Quasi-Peak/Average EMI detect mode • Built-in 2FSK Analysis, AM/FM/ASK/FSK Demodulation & Analysis • Built-in P1dB point, Harmonic, CHPW, OCBW, ACPR, SEM, TOI, CNR, CTB, CSO, N-dB bandwidth, Noise Marker, Frequency Counter, TDP, Gated Sweep • Built-in Spectrogram, Topographic and Split-Window Display Modes • Remote control EMI measurement software: SpectrumShot • Remote Control Interface: LAN, USB, RS-232 • Options: Tracking Generator, GPIB Interface
