Munekata MIW71-1 / MIW71-2 / MIW72-1 / MIW72-2 / MIW81-1 / MIW81-2 IMPULSE WELDER

Controlled Impulse Heat Staking for Thermoplastic Assembly

Munekata impulse welders use an electrically heated tip followed by controlled cooling to form and join thermoplastic features in automotive, electronics and precision-manufacturing assemblies.

The MIW71 models provide timer-based welding for single-point and tip-block applications, while MIW72 configurations add two-point control. MIW81 units provide selectable temperature-control and timer-control operation for applications requiring monitored heat-tip conditions.

6 modelsMIW71, MIW72 and MIW81 configurations covered
5–15 sManufacturer-listed typical welding process time
0.4–0.5 MPaRequired compressed-air pressure
100/200 VModel-dependent AC input supplies

The impulse tip heats rapidly by Joule heating to soften or melt the plastic, after which compressed cooling air helps solidify the formed joint. With suitable heat-tip and fixture design, this process can secure plastic-to-plastic joints, embedded nuts, mesh, membranes and automotive interior parts.

Electrical supply, tip geometry, tooling, sensor connections and temperature-control capability vary by model. Multi-point production systems are engineered separately and should not be equated with the channel capacity of the six standard controllers.

Rapid Heating and Active Cooling

Joule-heated tooling forms thermoplastics; forced air then solidifies the joint.

Timer-Control MIW71 Models

Choose single-point/manual or slide-mounted configurations depending on application.

Two-Point MIW72 Control

MIW72 family supports coordinated operation of two welding points.

Temperature-Control MIW81 Models

Switch between temperature and timer control with appropriate heat-tip sensing.

Configurable Heat Tips and Fixtures

Use grip, slide or tip-block tools sized to part geometry and weld location.

Production-Line Integration

Program selection and optional error/air-pressure monitoring support automation integration.

Automotive Interior Trim

Join door trims, instrument-panel components, pillars and molded plastic retainers.

Lighting and Lens Assemblies

Stake plastic bosses around lens housings and lamp components.

Electronic Enclosures

Secure circuit boards and molded inserts inside electrical product housings.

Plastic and Mesh Joining

Fix metal screens or filters into plastic parts without conventional through-holes.

Membrane and Nonwoven Attachment

Bond compatible membranes or fibrous inserts to molded parts after trial qualification.

Custom Multi-Point Welding Cells

Combine tooling and controls for high-throughput industrial resin assembly.

SpecificationMIW71-1MIW71-2MIW72-1MIW72-2MIW81-1MIW81-2
Control typeTimer / phaseTimer / phaseTimer / phase, 2-pointTimer / phase, 2-pointTemperature or timerTemperature or timer
AC input100 V200 V100 V200 V100/200 V family100/200 V family
Power consumption265 W364 W455 W707 W270–370 W family270–370 W family
Required air pressure0.4–0.5 MPa0.4–0.5 MPa0.4–0.5 MPa0.4–0.5 MPa0.4–0.5 MPa0.4–0.5 MPa
Welding cycle (typ.)5–15 s5–15 s5–15 s5–15 s5–15 s5–15 s
Heat-tip detailsStandard Ø2–Ø7 (ref.)Special heat tipStandard Ø2–Ø7Special heat tipSpecial heat tip; Ø2.5–Ø7 familySpecial heat tip; Ø2.5–Ø7 family
Controller dimensions W×D×H304×212×130 mm400×330×160 mm400×330×160 mm400×330×160 mm333×280×160 mm family333×280×160 mm family
Mass6.5 kg12.5 kg14.0 kg18.5 kg9/12 kg family9/12 kg family

Manufacturer lists MIW81-1/81-2 jointly as 100/200 V, 270–370 W and 9/12 kg without an unambiguous model-to-value mapping in the referenced table. Confirm the exact ordered variant, tooling and air requirements.
